Powertek Automatic Panel Saw is a high-performance panel cutting machine designed for precision cutting of plywood, particle board, MDF, and other wood-based panels. It is engineered to deliver accurate cuts, smooth operation, and consistent performance for professional woodworking and furniture manufacturing applications.
Built with a robust construction and automatic saw blade movement, the machine provides reliable panel processing with high cutting accuracy. Its powerful 7.5 HP main saw motor, precision cutting system, and durable construction make it suitable for demanding production environments where efficiency and long-lasting performance are important.
Key Features
- Heavy-duty construction for demanding industrial applications
- High cutting accuracy for precise panel processing
- Vibration-free performance for smooth and stable operation
- Maximum efficiency for productive woodworking operations
- User-friendly operation for convenient machine handling
- Long-lasting durability for reliable continuous performance
Powertek Automatic Panel Saw is an ideal solution for professional furniture manufacturers, woodworking industries, and panel processing units requiring precision, efficiency, and dependable cutting performance. Its powerful construction and advanced cutting mechanism ensure reliable operation for regular production requirements.
Product Specifications
| Specifications | Unit | Technical Parameters |
|---|---|---|
| Sliding Table Length | MM | 3200 |
| Sliding Table Width | MM | 420 |
| Max. Diameter Saw Blade | MM | 355 × 30 |
| Saw Blade Speed | RPM | 3000 / 4000 / 5000 |
| Tilting of Saw Blade | DEGREE | 45° (manual) |
| Max. Cutting Depth at 90° | MM | 85 |
| Max. Cutting Depth at 45° | MM | 50 |
| Up-Down Movement of Saw Blade | Auto | |
| Motor For Saw Blade | HP | 7.5 |
| Max. Diameter Scoring Blade | MM | 120 × 20 |
| Scoring Blade Speed | RPM | 8000 |
| Lateral Adjustment Scoring Blade | MM | ± 3 |
| Max. Depth of Cut off Scoring Blade | MM | 5 |
| Motor For Scoring Unit | HP | 1 |
| Cutting Width / Rip Capacity | MM | 1250 |
| Dimension Main Saw Table | MM | 600 × 1000 |
| Dimension Extension Table | MM | 800 × 1000 |
| Dimension Cross Cut Table | MM | 1500 × 600 |
| Length Cross-Cut Fence | MM | 2000 (telescopes to 3200 mm) |
| Dust Extraction Port Diameter | MM | 100 & 50 |
| Machine Dimension (L × B × H) | MM | 3250 × 3250 × 900 |
| Approx. Net Weight | kg | 850 |
